Haro MTB

Aeras MicroShift

Aeras MicroShift

$619.99
$619.99 $619.99
Sale Out of Stock

SKU: 13621

Sizing Guide

SizeInchesCM
S5'1" - 5'6"155 - 167.5
M5'5" - 5'10"165 - 177.5
L5'9" - 6'2"175 - 187.5
XL6'1" - 6'4"185 - 192.5
XL+6'3" - 6'6"190 - 200

Color
Size

View full details

COMPATIBLE RACKS & BASKETS

  • Rack Configuration 1

    Pictured: Haro Fitness bike with City AM rear carrier & Hybrid AM Front Carrier. Compatible with Aeras MicroShift

    Shop Racks

  • Rack & Accessory Configuration 2

    Pictured: Haro Fitness bike with City AM rear carrier & Hybrid AM Front Carrier with Bakery Crate & ZAP EASY Top Bag. Compatible with Aeras MicroShift

    Shop crates & Bags

  • Rack & Accessory Configuration 3

    Pictured: Haro Fitness bike with City AM rear carrier & Hybrid AM Front Carrier with Dailey Large & Dailey Small Baskets. Compatible with Aeras MicroShift

    Shop Baskets

FEATURES

    SPECIFICATIONS

    FRAMESET
    Frame6061-T6 aluminum | Rider-tuned geometry | 68mm threaded BSA BB shell | Post mount
    ForkSuntour SF20 NEX HLO-DS | 63mm travel | Hydraulic Lockout | Post-mount
    Frame ShockN/A
    ColorsMatte Deep Waters
    DRIVETRAIN
    CranksProwheel TB-CY01 | 46/30T | 8-speed | 170 / 175mm
    PedalsVP | 990S | Nylon body with steel cages | Chromoly axles
    ChainKMC Z8.1 | 8-speed
    Bottom BracketFeimin FP-902W | Threaded BSA 68mm BB shell | 123mm spindle | Sealed cartridge
    Front DerailleurMicroshift FD-T202 | Top swing | 34.9mm band diameter
    Rear DerailleurMicroshift RD-M36L
    Derailleur ShifterMicroshift TS39-2 & FD-T202 | 2 x 8-speed
    Freewheel/CassetteMid-range | CS-M5008 8-Speed 11-34T | ED Black
    WHEELS
    TiresKenda Kwick Bitumen | 700 x 38c
    Wheels/RimsHaro 700c | 19mm inner width | 28h | Alloy double wall | Disc-brake specifc
    HubsKT-68 alloy 28H | Cassette rear hub | Front & rear quick release
    BRAKING SYSTEM
    BrakesTektro MD-M280 | Mechanical disc | IS 6-bolt rotors | F: 180mm, R: 160mm
    Brake LeversAlloy 3-finger
    OTHER COMPONENTS
    Grips/TapeHaro | Dual-density durometer | Active tuned
    HandlebarHaro Alloy | 25mm rise | 31.8mm | 9° sweep | 620mm / 640mm
    StemHaro Alloy | 7° rise | 70mm / 90mm / 100mm
    HeadsetHaro 1-1/8" threadless Internal | For 50mm OD headtube
    SaddleHaro | Dual-sport tuned padding | Weather-resistant cover
    Seat PostHaro Alloy | Micro-adjust | 27.2mm x 350mm | Zero-offset | 2-bolt design
    Seat ClampHaro Aluminum 31.8mm Quick release
    ExtrasRack and fender mounts

    GEOMETRY

    Geometry frame chart
    SIZESMLXLXL+
    A. Seat Tube (C-T)394mm (15.5")445mm (17.5")483mm (19")533mm (21")584mm (23")
    B. Top Tube (Effective)555mm (21.9")570mm (22.4")580mm (22.8")600mm (23.6")620mm (24.4")
    C. Head Tube Angle70.5°70.5°71°71.5°71.5°
    D. Seat Tube Angle73.5°73.5°73.5°73°73°
    E. Chainstay Length445mm (17.5")445mm (17.5")445mm (17.5")445mm (17.5")445mm (17.5")
    F. BB Drop60mm (2.4")60mm (2.4")60mm (2.4")60mm (2.4")60mm (2.4")
    G. Wheelbase1053mm (41.5")1069mm (42.1")1075mm (42.3")1085mm (42.7")1106mm (43.5")
    H. Head Tube Length120mm (4.7")140mm (5.5")160mm (6.3")190mm (7.5")220mm (8.7")
    I. Standover719mm (28.3")748mm (29.4")776mm (30.6")814mm (32")852mm (33.5")
    J. Stack Height537mm (21.1")555mm (21.9")576mm (22.7")607mm (23.9")635mm (25")
    K. Reach396mm (15.6")405mm (15.9")409mm (16.1")414mm (16.3")425mm (16.7")
    L. Fork Height401mm (15.8")401mm (15.8")401mm (15.8")401mm (15.8")401mm (15.8")
    M. Fork Offset45mm (1.8")45mm (1.8")45mm (1.8")45mm (1.8")45mm (1.8")
    N. Stem Length70mm90mm90mm100mm100mm
    O. Bar Width620mm620mm640mm640mm640mm
    P. Crank Length170mm170mm175mm175mm175mm
