Specifications| FRAMESET | |
|---|
| Frame | Haro Daley alloy full-suspension frame with raw anodized finish, 1-1/8" - 1-1/5" tapered head tube, 148mm Boost OLD, UDH derailleur hanger |
|---|
| Fork | Fox Float 36 Performance Elite with Grip X, 150mm travel |
|---|
| Frame Shock | Fox Float X Performance Elite, 140mm travel |
|---|
| Colors | Raw |
|---|
| Weight | 38.2 lbs 17.29 kg, (L) |
|---|
| DRIVETRAIN | |
|---|
| Cranks | Shimano XT, FC-M8120-1, 165mm, 32T chainring, 55:CL |
|---|
| Pedals | N/A |
|---|
| Chain | Shimano CN-M8100 HG 12-speed |
|---|
| Bottom Bracket | Shimano BB-MT501 BSA 68/73mm |
|---|
| Front Derailleur | N/A |
|---|
| Rear Derailleur | Shimano XT 12-speed, Shadow Plus, RD-M8100 |
|---|
| Derailleur Shifter | Shimano XT 12-speed, SL-M8100R |
|---|
| Freewheel/Cassette | Shimano XT 12-speed CS-M8100, Hyper Glide Plus, 10-51T |
|---|
| WHEELS | |
|---|
| Tires | Front: Vittoria Mazza 2.4", enduro G2.0 120TPI / Rear: Vittoria Martello 2.4" enduro G2.0 120TPI |
|---|
| Wheels/Rims | DT Swiss M 1900 wheel set |
|---|
| BRAKING SYSTEM | |
|---|
| Brakes | TRP Trail EVO 4-piston hydraulic disc with 203mm rotors, front & rear |
|---|
| Brake Levers | TRP Trail EVO |
|---|
| OTHER COMPONENTS | |
|---|
| Grips/Tape | WTB Wavelength 130mm lock-on |
|---|
| Handlebar | Race Face Chester 35mm OD, 35mm rise, 780mm wide |
|---|
| Stem | Race Face Chester 35mm ID, 40mm reach |
|---|
| Headset | FSA ORBIT 1.5E ZS/ NO.57E tapered, 44/56mm head tube |
|---|
| Saddle | WTB Volt Medium PU leather, flex-tuned, chromoly rails, with ABR corners |
|---|
| Seat Post | Kind Shock Rage-I, 34.9OD, sizes: Small 150mm, Medium 170mm, Large 190mm, X-Large 190MM |
|---|
| Seat Clamp | 3D Forged 6061 aluminum 38.9mm ID |
|---|
| Extras | Includes tubeless valves and sealant |
|---|
