Saguaro 2
Saguaro 2
Regular price
$1,799.99
Regular price
$2,399.99
Sale price
$1,799.99
Unit price
/
per
SKU: SKU:14442
Simple, slack and full-on fun. The Saguaro 29-inch hardtail is purpose built to be the most versatile bike in your quiver. Make no mistake, this hardcore hardtail is no XC bike. With an aggressive geometry and slack head angle that is more inclined to hauling down hills than pedaling up them, the Saguaro is stretched out in the front and shortened up in the back for a stable ride at speed. As one of our testers put it: "It makes mellow trails more fun". Hit the jumps, hammer the single track and rip the turns. The Saguaro is everything you need, and nothing you don't.
All three models of the Saguaro bike collection feature our heat-treated 6061 aluminum Saguaro frame with three spec levels to fit your needs (and budget).
Meet in the middle on the Saguaro level 2. Built on the same bulletproof alloy frame as the rest of the family, the Saguaro 2 has a Marzocchi Bomber Z2 fork, SRAM NX Eagle 12-speed drivetrain, tubeless tires and a TranzX dropper post in frame size-specific lengths. The perfect blend of value and high-performance fun.
Share
FEATURES
- Hydroformed, heat-treated 6061-T6 aluminum hardtail frame. Double-butted top and down tubes. Internal cable routing. Tapered head tube.
- Modern geometry: 64.5 degree head tube angle with a longer front triangle and shorter rear end.
- Marzocchi Bomber Z2 fork. 140mm travel. 44mm rake.
- WTB KOM Tough rims, 32 hole with CNC-ed, sealed 15mm thru-axle front and six-sealed bearing, 12mm Boost thru-axle (rear) hubs.
- NX Eagle 12-speed transmission.
- Tires: Tubeless Kenda Pinner 29 X 2.4" ATC (front)/Kenda Nevegal 2, 29 X 2.4"ATC (rear). Sealant included.
- TranzX JD-YSP39J dropper post, size-specific per frame size.
- TRP Slate Evo 4-piston hydraulic brakes, 203mm rotor front, 180mm rotor rear.
- Full 29er. Small size features "mullet" wheel configuration with 29" front, 27.5" rear
PRODUCT INFORMATION
SPECIFICATIONS
FRAMESET | |
---|---|
Frame | Hydroformed, heat-treated 6061-T6 aluminum hardtail frame. Double-butted top and down tubes. Internal cable routing. UDH derailleur hanger. Tapered head tube. Frame will accommodate up to 2.6" tires. |
Fork | Marzocchi Bomber Z2; 140mm travel. 44mm rake. |
Colors | Metallic Green, Matte Mauve |
DRIVETRAIN | |
Cranks | SRAM NX Eagle 32T, 170mm |
Pedals | |
Rear Derailleur | SRAM NX Eagle 12-speed |
Derailleur Shifter | SRAM NX Eagle 12-speed |
Freewheel/Cassette | SRAM Eagle 11-50T |
WHEELS | |
Tires | Tubeless Kenda Pinner 29 X 2.4" ATC (front)/Kenda Nevegal 2, 29 X 2.4" ATC (rear). Sealant included. Small size features 27.5 X 2.4" rear "mullet" configuration. |
Wheels/Rims | WTB, KOM Tough, 30MM, TCS 2.0, sleeved. 32H |
Front Hub | Fully sealed, CNC-machined alloy. 110x15mm boost thru-axle, 6-bolt disc. |
Rear Hub | Fully sealed, CNC-machined alloy. 148x12mm boost thru-axle, 6-bolt disc. |
BRAKING SYSTEM | |
Brakes | TRP Slate Evo 4-piston hydraulic. 203mm rotor (front)/180mm rotor (rear). |
OTHER COMPONENTS | |
Grips/Tape | WTB Wavelength lock-on |
Handlebar | Haro Alloy 800mm wide, 20mm Rise, 6° back sweep, 4° up sweep |
Stem | Satori Ursa 35mm reach, 0° rise |
Headset | FSA Orbit Tapered 1-1/8" - 1-1/5", 1.5E ZS/ NO.57E |
Saddle | WTB Volt Medium chromoly rails. PU Leather. Flex-tuned. |
Seat Post | TranzX JD-YSP39J dropper. Small 150mm, Medium 170mm, Large/X-Large 200mm |
Extras | Tubeless tire sealant included. |
GEOMETRY
SIZE | S | M | L | XL |
---|---|---|---|---|
Seat Tube (C-T) | 350mm | 405mm | 430mm | 480mm |
Top Tube (Effective) | 574.2mm | 601.2mm | 633.4mm | 650.7mm |
Head Tube Angle | 64.5° | 64.5° | 64.5° | 64.5° |
Seat Tube Angle | 76° | 76.5° | 76.5° | 76.5° |
Chainstay Length | 418mm | 430mm | 435mm | 435mm |
BB Drop | 50mm | 70mm | 70mm | 70mm |
Wheelbase | 1156.6mm | 1195.1mm | 1234.4mm | 1253.7mm |
Head Tube Length | 100mm | 110mm | 120mm | 130mm |
Standover | 694mm | 706mm | 709mm | 709mm |
Stack Height | 642.3mm | 650.8mm | 659.9mm | 668.9mm |
Reach | 420mm | 445mm | 475mm | 490mm |
Axle to Crown | ||||
Fork Offset | 44mm | 44mm | 44mm | 44mm |
Stem Length | ||||
Bar Width | ||||
Crank Length | ||||
Wheel Size | 29" Front / 27.5" Re | 29" | 29" | 29" |
SIZING GUIDE
Size | Inches | CM |
---|---|---|
S | 5" - 5' 6" | 153 - 166 |
M | 5' 4" - 5' 11" | 162 - 180 |
L | 5' 9"- 6' 2" | 175 - 187 |
XL | 6' - 6' 5" | 180 - 196 |
MANUALS, GUIDES & DOWNLOADS
Downloadable PDFs can be found in Manuals & Guides
*Specifications are subject to change without notice
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
