GEOMETRY
SIZE | XS | S |
---|---|---|
A. Seat Tube (C-T) | 355mm (14") | 406mm (16") |
B. Top Tube (Effective) | 550mm (21.7") | 572mm (22.5") |
C. Head Tube Angle | 70° | 70° |
D. Seat Tube Angle | 74° | 74° |
E. Chainstay Length | 445mm (17.5") | 445mm (17.5") |
F. BB Drop | 60mm (2.4") | 60mm (2.4") |
G. Wheelbase | 1058mm (41.7") | 1081mm (42.6") |
H. Head Tube Length | 105mm (4.1") | 115mm (4.5") |
I. Standover | 682mm (26.9") | 695mm (27.4") |
J. Stack Height | 587mm (23.1") | 596mm (23.5") |
K. Reach | 381mm (15") | 400mm (15.7") |
L. Fork Height | 468mm (18.4") | 468mm (18.4") |
M. Fork Offset | 42mm (1.7") | 42mm (1.7") |
N. Stem Length | 75mm | 90mm |
O. Bar Width | 620mm | 620mm |
P. Crank Length | 170mm | 170mm |
