Del Sol

31102

Railer Plus

*Actual retail price may vary based on any added dealer freight, tax, and assembly fees

Take one part plus bike, one part mountain bike, and one part cruiser and whaddya get? This bike. And it's splendid because you get the gearing of a mountain bike, the supple ride of a plus bike, and the easygoing simplicity of a cruiser. Did we intend that from the start with the Railer Plus? Well, the jury's still out on the one my friend, but one thing's for sure: it's a winning combo, intentional or otherwise, so we'll take it.

Customer Reviews

No reviews yet
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Features

  • Wide, high-rise BMX-inspired handlebars provide comfort, laid-back positioning, and stylistic stability
  • Supple 26+ tires and wide rims smooth out bumps and provide float in sandy conditions
  • 8-speed gearing adds versatility to a laid-back cruiser making the Railer Plus equally adept at climbing hills to the beach overlook or blasting down the bike path
  • Pedal-forward positioning allows for full leg extension while still easily putting a foot down at stop signs
Specifications
FRAMESET
FrameRailer Plus | Rust-proof 6061 heat-treated aluminum | Tig-welded constuction | Easygoing geometry | Pedal-forward design | 73mm threaded BSA bottom bracket shell | I.S. disc brake mount | 141mm spacing | Cartridge kickstand mount
ForkRailer Hi-Ten Plus Cruiser
ColorsBrushed Alloy, Black, Vivid Blue
Weight41 lbs
DRIVETRAIN
Cranks3-piece | Forged alloy | 42T chainring with dual-guide design | 170mm length
PedalsBoardwalk cruiser | Shock-absorbing Kraton inserts
ChainKMC Z8.3 | 8-speed
Bottom BracketThreaded 73mm BSA shell | JIS square taper | Sealed cartridge
Front DerailleurN/A
Rear DerailleurShimano Tourney TX800 | 8-speed
Derailleur ShifterShimano Revo twist shifter
Freewheel/CassetteShimano Tourney CS-HG200-8 cassette | 14-32T | 8-speed
WHEELS
TiresRailer Plus 26 x 3.0"
Wheels/RimsAlloy | Width (internal): 50mm | 36h
Front HubSteel | 3/8" x 100mm | Bolt-on | I.S. 6-bolt disc | 36h
Rear HubAlloy | 3/8" x 141mm | Bolt-on | I.S. 6-bolt disc | HG freehub | 36h
BRAKING SYSTEM
BrakesTektro MD280 | Mechanical disc brake | I.S. mount | I.S. 6-bolt 180/160mm rotors
Brake LeversAlloy | Linear pull
OTHER COMPONENTS
Grips/TapeDel Sol Foam Cruiser
HandlebarRailer Throwback | 805mm wide
StemRailer BMX Throwback | Alloy | ϕ25.4 bar bore | 1-1/8" threadless
Headset1-1/8" integrated | threaded
SaddleDel Sol Cruiser HD-tuned Lounge Chair
Seat PostAlloy | 27.2mm x 350mm
Seat ClampAlloy | ϕ 31.8mm | Bolt-on
ExtrasRear moto fender | Rack mounts | Steel cartridge kickstand
Geometry & Sizing
SIZEMensST
A. Top Tube (Effective)690mm (27.2")676mm (26.6")
B. Seat Tube (C-T)458mm (18")422mm (16.6")
C. Standover Height777mm (30.6")590mm (23.2")
D. Head Tube Length219mm (8.6")219mm (8.6")
E. Head Angle67°67°
F. Seat Angle69.5°69.5°
G. Wheelbase
H. Chainstay537mm (21.1")537mm (21.1")
I. BB Drop50mm (1.9")50mm (1.9")
J. Stem Length63.5mm63.5mm
K. Bar Width805mm805mm
L. Crank Length170mm170mm
M. Wheel Size26+26+



*Specifications are subject to change without notice
