Skwad
Skwad
Regular price
$2,299.99
Regular price
$2,299.99
Sale price
$2,299.99
Unit price
/
per
SKU: SKU:32772
Ready to rip through the neighborhood, run errands, or go off-road? the Skwad is the perfect bike to meet up with your crew and take it all on. With up to 40 miles of range, this is your true down-for-whatever ride. The Skwad has a retro look, but it's all modern with oversized tires that are at home on pavement and adventurous enough for shortcuts. With a comfy, cafe-style seat, Haro Baseline 9.5" BMX handlebars and folding foot pegs, you get unmatched comfort and room for a friend. Alloy side-plates under the seat give you options to strap down your gear. Quick, safe and stable, the Skwad is your ticket to freedom. Round up your squad and get after it!
OWNERS MANUAL
OWNERS MANUAL
Share
COMPATIBLE RACKS & ACCESSORIES
-
-
Rack & Accessory Configuration 2
Shop Crates & BagsPictured: Skwad Hybrid UNI Front Carrier with ZAP EASY Top Bag
-
Rack & Accessory Configuration 3
Shop BasketsPictured: Skwad Hybrid UNI Front Carrier with Bakery Crate
Collapsible content
FEATURES
- 6061 T6 Aluminium, tapered head tube, internal downtube battery and Built in Grid mounting plate
- Bafang 750W drive unit
- 48v, 13.2AH internal downtube battery, UL certified
- 40 Mile plus range
- Dual piston hydraulic disc brake with 180mm rotors
- MX Style front headlight and rear brake alert light
- Left side thumb throttle
- Alloy 6-spoke mag wheels with 20 x 4" Kenda tires
- Ebike classification: Class 2, 750W/20MPH
SPECIFICATIONS
FRAMESET | |
---|---|
Frame | 6061 T6 Aluminium; tapered head tube and internal battery; Built in Grid mounting plate |
Fork | 100mm travel I Triple crown I Aluminum 32mm stanchions |
Colors | Matte Black, Pearl White, Split Pea Green |
DRIVETRAIN | |
Cranks | Forged aluminum | 170MM |
Bottom Bracket | Square Tapper | 73mm | 148mm Spindle I Cadence Sensor |
Sprocket | 42T Alloy Chainring Alloy Guard |
Gearing | |
Pedals | 9/16" Cro-Mo Axle, Alloy Body |
Chain | KMC Z7 | 7SPD |
Rear Derailleur | Microshift RD-M26L |
Derailleur Shifter | Microshift TS39-7 |
Cassette | Shimano mf-TZ500-7SPD 14-28T |
WHEELS | |
Tires | Kenda Krusade 20"X4" |
Rims | Bafang Alloy 6 Spoke Mag Wheel |
BRAKING SYSTEM | |
Brake | Rush Dual Piston | Open System | 180mm Rotors | STD Mount |
Brake Lever | Radius 2.5 Finger | Sensor Control Cut Off | Reach Adjustment |
Drive Unit | Bafang 750W. Class 2, 750W/20MPH |
Battery | 48V | 13.2AH | 13S4P | 3300mAh | BAK | UL certified |
OTHER COMPONENTS | |
Grips | Dual locking 135mm Velo Grips |
Handlebar | Haro Baseline 9.5" |
Stem | Haro Baseline 48mm EXT. |
Headset | 1-1/8" - 1-1/5" tappered internal headset |
Seat | Haro Cafe |
Extras | Rear brake Light; Front MX style headlight; left thumb throttle |
GEOMETRY
Size | A. Head Angle | B. Seat Angle | C. Top Tube | D. Seat Tube | E. Chainstay | F. BB Height | G. Stand Over |
---|---|---|---|---|---|---|---|
20 | 71° | ° | 26.30" (668mm) | 18.1" (460mm) | 18.3" (466mm) | 12" (304mm) |
*Specifications are subject to change without notice
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
