Del Sol

31122

Tradewind HD

Customer Reviews

No reviews yet
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Features

Specifications

FRAMESET
FrameTradewind HD | Rust-proof 6061 heat-treated aluminum | Tig-welded constuction | Easygoing geometry | Pedal-forward design | 68mm threaded BSA bottom bracket shell | Coaster brake mount | 110mm spacing | Cartridge kickstand mount
ForkClassic raked cruiser | Steel | 1" threaded
ColorsNeon Red, Neon Green
Weight30lbs
DRIVETRAIN
Cranks3-piece | Forged alloy | 44T alloy chainring | 170mm length
PedalsBoardwalk cruiser | Shock-absorbing Kraton inserts
ChainKMC S1 Rust Buster
Bottom BracketThreaded 68mm BSA | JIS square taper | Sealed cartridge
Front DerailleurN/A
Rear DerailleurN/A
Derailleur ShifterN/A
Freewheel/Cassette
WHEELS
TiresKenda Kruiser 26x2.125" | Thorn-proof inner tubes
Wheels/RimsAlloy | Width (internal): 24mm | 36 hole
BRAKING SYSTEM
BrakesCoaster brake
Brake LeversN/A
OTHER COMPONENTS
Grips/TapeKraton | Closed end with internal plug
Handle BarHeat-treated alloy SuperCruise | 700mm wide
StemQuill | Alloy | 30° rise | ϕ25.4 bar bore | 100mm length
HeadsetAlloy | 1-1/8" integrated | threaded | Semi-cartridge bearings
SaddleDel Sol elastomer Cruiser
Seat PostAlloy | 27.2mm x 400mm
Seat ClampAlloy | Quick release | ϕ 31.8mm | Anti-rust zinc-nickel alloy coating on internal cam hardware
ExtrasRack and fender mounts | Steel cartridge kickstand

Geometry & Sizing

SIZEMensWomens
A. Top Tube (Effective)689mm (27.1")689mm (27.1")
B. Seat Tube (C-T)432mm (17")390mm (15.4")
C. Standover Height727mm (28.6")529mm (20.8")
D. Head Tube Length190mm (7.5")190mm (7.5")
E. Head Angle67°67°
F. Seat Angle67°67°
G. Wheelbase1196mm (47.1")1196mm (47.1")
H. Chainstay537mm (21.1")537mm (21.1")
I. BB Drop45mm (1.8")45mm (1.8")
J. Stem Length100mm100mm
K. Bar Width700mm700mm
L. Crank Length170mm170mm
M. Wheel Size2626
